| Part Number | Thickness |
|---|---|
| FSD 40894-54 | 0.25mm |
| FSD 40894-53 | 0.50mm |
| FSD 40894-52 | 1.00mm |
| FSD 40894-51 | 2.00mm |
| Set Number | Stackup | 2.00mm | 1.00mm | 0.50mm | 0.25mm |
|---|---|---|---|---|---|
| -FSD 40894 | 4.5mm Set | 1 | 2 | 1 | 0 |
| **FSD 40894 | 5.0mm Set | 1 | 1 | 3 | 2 |
| ***FSD 40894 | 6.0mm Set | 2 | 1 | 2 | 0 |
|
